Resolution: 20,000 Count for L, C, R and 1,000 Count for D, Q, and q

Measurement Parameters: R, L, C, D, Q,

Selectable Test Frequency : 120Hz / 1kHz

Measurement Ranges :

　　　　　　L: 2mH to 1,000H; C: 2,000pF to 10mF; R: 20W to 10MW

　　　　　　Q: .000 to 999 Auto; D: .000 to 999 Auto; q: ± 90°

Parallel and Serial Test Mode

Auto and Manual Ranging

0.5% Basic Accuracy for Resistance Measurement

0.7% Basic Accuracy for Capacitance and Inductance Measurement

Tolerance Mode: 1%, 5%, 10%, and 20%

Max / Min / Avg Dynamic Recording

Relative Mode for Reading Correlation and Comparison Applications

Auto Protective Fuse Check

Self-Calibration for Calibrating the Meter's Internal Parameters as well as External Connector Residuals

Powered by Battery or External AC/DC Adapter

Auto Power Off

Low Battery Indicator

Optical RS-232 Interface

CE Mark
