![]() | | Specifications | | Current Measurement | | Range: | 0-1 A AC or DC | | Resolution: | 1 mA | | Accuracy: | 0.2% + 2 LSD (DC) | | | | Range: | 0-30 mA | | Resolution: | 0.001 mA | | Accuracy: | 0.05% + 2 LSD |
| | Current Sourcing | | Range: | 0-20 mA or 4-20 mA | | Resolution: | 0.05% of span | | Drive Capability: | 24 V Compliance or 1200 Ω @ 20 mA |
| | Frequency | | to 19.999 kHz, 0.005% + 1 LSD |
| | Continuity | | Beeps for resistance < 100 Ω |
| | Voltage measurement | | Range: | 0-1000 V AC (true-rms) or DC | | Resolution: | 0.1 mV to 1.0 V | | Accuracy: | 0.1% Rdg + 1 LSD (VDC) |
| | Resistance measurement | | | Diode test | | 2.0 V shows diode voltage drop |
| | Display current and % of span | | | Auto step, auto ramp | |
| Environmental Specifications | | Operating Temperature | | | Storage Temperature | | | Humidity (Without Condensation) | | 95% up to 30 ºC | | 75% up to 40 ºC | | 45% up to 50 ºC | | 35% up to 55 ºC |
| | Temperature Coefficient | | 0.05 x (specified accuracy) per ºC (for temperatures < 18 ºC or > 28 ºC) |
|
| Safety Specifications | | Electrical Safety | | Designed in accordance with IEC 1010-1, ANSI/ISA S82.01-1994 and CAN/CSA C22.2 No. 1010.1-92 |
| | Overvoltage category | | IEC 1010-1 CAT III 1000 V | | IEC 1010-1 CAT IV 600 V |
| | Maximum voltage | |
| Mechanical & General Specifications | | Size | | 50 x 100 x 203 mm (1.25" H x 3.41"W x 7.35" L) |
| | Weight | | | Batteries | | | Warranty | | | Battery Life | | 140 hours typical (measurement), 10 hours typical (sourcing 20 mA) |
| | Shock & Vibration | | Random, 2 g, 5-500 Hz | | 1 meter drop test |
|
|
|
