MSG-2050A GPS Signal Generator

The MSG-2050A is a GPS signal generator designed for generating a simulation signal of GPS (Global Positioning System) satellite, and this unit can be used for adjustment and inspection of car-navigation system with GPS receivers and relative devices.
All operation can be controlled by GP-IB,RS-232C and newly added serial interface,USB for simplifying the operation, and the output level can be switched quickly over a range from -80dBm to -140dBm.
All NAVI data can be preset by GP-IB, RS-232C and also USB, and a Z- count automatic increment function can be preset.
Since this unit is designed to be compact, lightweight, economical and easy-operation signal generators, it is most suitable for using in production lines.

■	Frequency stability of internal reference oscillator is less than 5×10^-8.
■	Rapid changing output level and the level range is from -80dBm to-140dBm.
■	The output terminal is DC-cut to able to connect to the powered antenna cable.
■	All NAVI data preset by GP-IB and also RS-232S USB.
■	A Z-count automatic increment function can be preset.
■	This unit is designed to be compact, light weight and economical suitable for production lines.
*	The application program is attached.

Frequency
Frequency	1.57542GHz (L1 Band)
Accuracy	5×10^-8

Output
Level range	-80dBm to -140dBm
VFD display	-80 to -140
Accuracy	±1.0dB
Output impedance	50Ω, VSWR 1.2 or less
Sprious output	-40dB or 2nd harmonic
Setting	Shuttle knob, GP-IB, RS-232C, USB (Min.1dB)

Modulation
Modulation method	Direct differential modulations of BPSK spectrum
Modulation code	37 kinds C/A codes (1023-bit serues gold codes)
Channel	SV1 to SV37
Modulation frequency	1.023MHz clock
Data modulation	C/A code synchronized frequency division, 50bps BPSK
NAVI data	50bps test pattern
Setting	Shuttle knob, GP-IB, RS-232C, Non-modulation, USB
Z count	Automatic incremdent function being synchronized with real time clock (RTC) is proivded
Display	Displayed with VFD

Interface Function
Parallel interface	GP-IB (Conforms to IEEE Std. 488-1975)
Serial interface	RS-232C Ｄ-sub 9-pins (Male)，USB TYPE B (Female)

General Data
Operating temperature range	0ºC to +40ºC
Guarantee temperature range	+10ºC to +35ºC
Power requirement	AC. 90V to 240V, 50/60Hz
Power consumption	15VA max.
Dimensions	Approx. 240(W) × 100(H) × 350(D)mm
Weight	Approx. 3.7kg
