Ⅱ. Technical Specification

-.Function ; Measurement of AC leakage current, AC current and on-line measurement

-.Power ; Zn-Mn dry battery,6F22,9V -.Size of clamp ;Φ68mm

-.Range; 0.00mA~1200A -.Resolution; 0.01mA -.Accuracy ;(23℃±3℃, below 70%RH)
;0.00mA~59.9A: ±1.5%±5dgt ;60.0A~199A: ±2%±5dgt
'200A~599A: ±3%±5dgt ; 600A~1200A: ±4%±5dgt

-.Test Mode ;Clip-on CT, integral mode -.Display Mode ; Four digits LCD display

-.Dimension; HxWxT:224mmX115mmX43mm

-.LCD Dimension ;35mm×21.5mm;display domain:32mm×15mm

-.Sampling Rate; about 2 times/s -.Range Shift ;Automatically -.Voltage Range ;AC600V

-.USB Interface; Data stored in the memory of the meter via USB upload to PC, or on-line monitoring

-.USB line ; 1.5m -.Storage ;99units，all used when display FULL

-.Peak Hold; Push HOLD without release, the meter will show the peak value during the pushing period

-.Reading Hold ;DH indicating the reading is hold -.Out of Range; OL indicating the current is out of range

-.Auto Power-of;f 5 Minutes after power on, it will power off automatically to lower the power consumption

-.Battery Voltage; Indicating the battery voltage is lower than 7.2V.Then the battery have to be changed

-.Weight; 515g(including the battery) -.Consumption ;About 15mW

-.Temperature and Humidity; Working: 0℃~40℃,below 80%rh,

-.Temperature and Humidity; Storage: -10℃~60℃,below 70%rh

-.Insulating Strength ;AC2kV/rms.(between the alloy of the clamp and the housing)

-.Applicable Safety Rules; IEC1010-1、IEC1010-2-032、pollution, etc 2、CAT Ⅲ(600V)

-.Accessories ;Meter: 1pc; toolkit:1pc; USB communication line:1 pc; disk: 1 pc.
